Home / Products / Perforating Machine / CHZN OEM 1700MM Electric Kraft Paper Hole Punching Machine Automatic Peforating Rewind Machine

Recommended Products

Cross Cutting Machine
Cross Cutting Machine
Decoiler Machine
Decoiler Machine
Embossing Machine
Embossing Machine
Embossing Roller
Embossing Roller
leveller
Leveller
Nonferrous Metal
Nonferrous Metal
Perforating Machine
Perforating Machine

Normal FAQs

  • Q Are you a factory or a trading company?

    A
    We are factory with foreign trade department.

  • Q When your company was founded?

    A
    Our company was founded in 2014.

  • Q Do you have any certificates?

    A
    We have passed IS09001 and IS014000.

  • Q What are the maintenance skills of embossing roller？

    A
    It is necessary to clean the embossing roller to protect the pattern, such as removing rust by acid pickling and removing oil stains by organic matter. And you can use sand blasting treatment to increase surface roughness of the embossing roller, it can improve the binding force between the surface pattern and the embossing roller. Finally, the embossing roller should be kept dry to prevent rusting again.

loading

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

CHZN OEM 1700MM Electric Kraft Paper Hole Punching Machine Automatic Peforating Rewind Machine

Availability:
Quantity:
Inquire Add to Basket

  • HK-670

  • CHZN

Type of punching machine: Vertical two-roller punching machine

Effective size of workbench: 1700MM

Single needle roller diameter: 240MM

Capacity: 70- 120m/min

Punch adjustment: reducer

Transmission device: Adopt frequency conversion speed regulation

Punching form: upper and lower roller pressing

Weight: 2500KG (based on actual weight)

Cycloidal pinwheel reducer: XWD7- 11- 7.5

Punch machine frame: steel plate structure

Material printed: Kraft paper

Arrangement format: tic-tac-toe arrangement

Uncoiling diameter: 1200mm

Rewinding frame: Steel plate structure

Rewinding mode: Motor automatic rewinding (ground roller rewinding)

Rewinding load-bearing: 200Kg

Rewinding diameter: 300mm

Machine dimensions: 2000MM*1900MM*1300MM (based on the actual object)

主图31


Previous:
Next:
Kraft Paper Punching Machine automatic eyelet punching machine electric paper punching machinery automatic punching machine Kraft Paper Peforating Machine Automatic Peforating Rewind Machine
